3D Structure — Nanobody–Epitope Complex
Loading 3D structure…
anti-GFP nanobody complex
PDB 6LR7
■ nanobody (VHH) ■ antigen ■ epitope (30)
Drag to rotate · scroll to zoom
Interactive model of the VHH bound to its structural epitope on GFP (from experimental complex PDB 6LR7). Nanobody in blue, epitope contact residues in red. For research visualization.
Product Description
| Product Name | Anti-GFP Nanobody (VHH), Recombinant, Purified |
| Description | A purified, engineered single-domain antibody (VHH/nanobody) that binds GFP and its common derivatives with high specificity. Ideal for one-step immunoprecipitation of GFP-fusion proteins, IF, and live-cell imaging. |
| Target / Specificity | Green fluorescent protein (GFP) and derivatives (eGFP, YFP, CFP, Venus, Citrine, sfGFP) |
| Sequence | This nanobody is an engineered variant based on PDB 6LR7, with higher affinity and stability than the original published sequence. |
| Format | Purified recombinant single-domain antibody (VHH / nanobody), carrier-free |
| Tag & Expression | C-terminal 6×His tag; secreted from HEK293 cells and purified by one-step IMAC from the culture medium. |
| Molecular Weight | ~14 kDa (single VHH domain + His6; ~1/10 the size of a conventional IgG) |
| Purity | >90% by SDS-PAGE |
| Quantity | 100 µg |
| Formulation | PBS with 50% glycerol (carrier-free); 0.02% sodium azide |
| Applications | Immunoprecipitation (IP), pull-down of GFP fusions, immunofluorescence (IF), Western blot (WB), ELISA, live-cell imaging |
| Structural Epitope | Epitope mapped from the experimental VHH–antigen complex (PDB 6LR7); 30 antigen contact residues within 5 Å. An interactive 3D complex model is shown on this page. |
| Storage | Store at -20°C; avoid repeated freeze-thaw. Stable 1 year. |
| Advantages | Nanobodies are the smallest functional antibody fragments: exceptional thermal and chemical stability, single-domain, high-yield recombinant production, and access to cryptic epitopes and dense tissue that conventional antibodies cannot reach. |
Product Documents
DatasheetEG-NB-GFP01 Product Datasheet
