3D Structure — Nanobody–Epitope Complex
Loading 3D structure…
anti-EGFR nanobody complex
PDB 4KRM
■ nanobody (VHH) ■ antigen ■ epitope (24)
Drag to rotate · scroll to zoom
Interactive model of the VHH bound to its structural epitope on EGFR (from experimental complex PDB 4KRM). Nanobody in blue, epitope contact residues in red. For research visualization.
Product Description
| Product Name | Anti-EGFR Nanobody (VHH), Recombinant, Purified |
| Description | A purified, engineered VHH nanobody against the ectodomain of human EGFR. The single-domain format penetrates tumor spheroids and dense tissue where full antibodies are limited. |
| Target / Specificity | Human epidermal growth factor receptor (EGFR / ErbB1 / HER1) |
| Sequence | This nanobody is an engineered variant based on PDB 4KRM, with higher affinity and stability than the original published sequence. |
| Format | Purified recombinant single-domain antibody (VHH / nanobody), carrier-free |
| Tag & Expression | C-terminal 6×His tag; secreted from HEK293 cells and purified by one-step IMAC from the culture medium. |
| Molecular Weight | ~14 kDa (single VHH domain + His6; ~1/10 the size of a conventional IgG) |
| Purity | >90% by SDS-PAGE |
| Quantity | 100 µg |
| Formulation | PBS with 50% glycerol (carrier-free); 0.02% sodium azide |
| Applications | Flow cytometry, IF, IP, ELISA, receptor-targeting and tumor-penetration research |
| Structural Epitope | Epitope mapped from the experimental VHH–antigen complex (PDB 4KRM); 24 antigen contact residues within 5 Å. An interactive 3D complex model is shown on this page. |
| Storage | Store at -20°C; avoid repeated freeze-thaw. Stable 1 year. |
| Advantages | Nanobodies are the smallest functional antibody fragments: exceptional thermal and chemical stability, single-domain, high-yield recombinant production, and access to cryptic epitopes and dense tissue that conventional antibodies cannot reach. |
Product Documents
DatasheetEG-NB-EGFR01 Product Datasheet
