3D Structure — Nanobody–Epitope Complex
Loading 3D structure…
anti-SARS-CoV-2 Spike RBD nanobody complex
PDB 7KLW
■ nanobody (VHH) ■ antigen ■ epitope (22)
Drag to rotate · scroll to zoom
Interactive model of the VHH bound to its structural epitope on SARS-CoV-2 Spike RBD (from experimental complex PDB 7KLW). Nanobody in blue, epitope contact residues in red. For research visualization.
Product Description
| Product Name | Anti-SARS-CoV-2 Spike Nanobody (VHH), Recombinant, Purified |
| Description | A purified, engineered VHH nanobody against the SARS-CoV-2 Spike S1 subunit for neutralization and diagnostic research. |
| Target / Specificity | SARS-CoV-2 Spike glycoprotein (S1 / receptor-binding domain) |
| Sequence | This nanobody is an engineered variant based on PDB 7KLW, with higher affinity and stability than the original published sequence. |
| Format | Purified recombinant single-domain antibody (VHH / nanobody), carrier-free |
| Tag & Expression | C-terminal 6×His tag; secreted from HEK293 cells and purified by one-step IMAC from the culture medium. |
| Molecular Weight | ~14 kDa (single VHH domain + His6; ~1/10 the size of a conventional IgG) |
| Purity | >90% by SDS-PAGE |
| Quantity | 100 µg |
| Formulation | PBS with 50% glycerol (carrier-free); 0.02% sodium azide |
| Applications | ELISA, WB, IF, neutralization and diagnostic research |
| Structural Epitope | Epitope mapped from the experimental VHH–antigen complex (PDB 7KLW); 22 antigen contact residues within 5 Å. An interactive 3D complex model is shown on this page. |
| Storage | Store at -20°C; avoid repeated freeze-thaw. Stable 1 year. |
| Advantages | Nanobodies are the smallest functional antibody fragments: exceptional thermal and chemical stability, single-domain, high-yield recombinant production, and access to cryptic epitopes and dense tissue that conventional antibodies cannot reach. |
